HeatPak HBS2800 Hot Water Heating System

0% Off

HeatPak HBS2800 Hot Water Heating System


2860 Litres of decarbonised 65°c hot water for commercial applications


    This combination does not exist.

    Product Code:

    Product Features:
    • Typically used as an alternative to gas hot water for motels, hotels, rest homes, commercial kitchens and other venues.
    • Potable domestic hot water with a circulating ring main loop.
    • In the first hour, the HBS2800 can produce 2860 Litres of hot water.
    • Continuous hot water production of 460L/hr @ 7°C ambient air temperature and 65°C outlet temperature.
    • Our heat pump *SCOP of 3.5 super high efficiency 350% ensures low running costs.
    • Twin heat pumps provide peace of mind and continuity of hot water.
    • Designed and built with "Plug & Play" in mind for fast and simple site installation.
    • It is fully wired with an onboard electrical switchboard requiring only a single electrical connection.
    • Backup electrical elements for ring main heating and emergencies.
    • Easy onsite piping to 3 x high flow threaded connection points: 40mm cold water, 40mm hot water, 25mm hot water return.
    • 1 x 50mm drain connection - no additional drain connections are required.
    • High flow 40mm thread connections
    • Thermostatic hot water mixing valve for precise ring main temperature control and ring main thermal disinfection settings available for legionella control.
    • Smart circulating pumps for superior energy efficiency.
    • Fully insulated pipework for low heat loss.
    • 2205 Duplex stainless steel cylinders for all potable water conditions and mains pressure.
    • High-quality components and pipework.
    • Heavy duty, engineered, fully welded aluminium frame with internal cylinder support and restraint. Lifting lugs makes site installation quick and can be relocated if the site needs to change.
    • All HeatPaks are fitted with a hold-down bolt system; no additional brackets are needed.
    • Exterior cladding is aluminium composite panel with options of custom colour/print wraps to match the building colour or surrounding environment available if desired
    • Heavy-duty lockable swing doors for easy servicing and security.
    • Delivered fully pre-commissioned for fast site startup.
    • Video operation and installation instructions are included.

    On Application
    Share :

    Using natural CO₂ as the refrigerant and achieving a high coefficient of performance (COP), CO₂ heat pumps offer both ecological and financial benefits.  Our plug-and-play hot water heating systems provide *2860 Litres of decarbonised 65°c hot water for commercial installations.
